The 14ET Super Duty Tandem Axle Equipment Trailer from Big Tex has an 83-inch width between the fenders, multiple length options and a flush floor, providing versatility and exceptional value. 7,000-pound axles give the 14ET added weight capacity for unmatched durability and strength.
SPECIFICATIONS:
AXLE - (2) 7,000# EZ Lube w/Electric Brakes
JACK - 12,000# Drop Leg Jack-Side Wind
TIRE - ST235/80 R-16 Load Range E
FLOOR - 2" Treated Pine or Douglas Fir*
FRAME - 6" Channel
WHEEL - 16" x 6"; Black Mod 8 Bolt
FINISH - Superior Quality Finish is Applied for a Highly Decorative and Protective Finish.
LIGHTS - L.E.D. D.O.T. Stop, Tail, Turn & Clearance
TONGUE - 6" Channel Fold Back/Wrap, 10" I-Beam on GN
COUPLER - Adjustable 2-5/16" 14,000# Cast
FENDERS - 9" x 72" Double Broke Diamond Plate w/Back (Removable)
G.V.W.R. - 14,000#
ELEC. PLUG - 7-Way RV
HITCH TYPE - Bumper Pull
SUSPENSION - Multi-Leaf Slipper Spring w/Equalizer
CROSSMEMBERS - 3" Channel on 16" Centers
FINISH - Steel is Cleaned to Ensure a Professional Smooth Finish.
SAFETY CHAINS - 3/8" Grd. 70 w/Safety Latch Hook (2 ea)
FRONT STOP RAIL - 3/16" Fabricated Front Stop Rail
G.A.W.R. (Ea. Axle) - 7,000#
THE 14ET ALSO COMES EQUIPPED WITH:
Rubrail and Tie Down Pockets Along Sides
36" Cleated Dovetail
3' Mega ramps
Adjustable 2-5/16" Demco EZ Latch Coupler
Fold Back/Wrap Tongue
12,000# Drop Leg Jack- Side Wind Against Bed
Fabricated Front Stop Rail
EZ Lube Hubs
Dexter Brand Axles
Nev-R-Adjust Electric Brakes on All Hubs
Cambered Axles
Double Broke Diamond Plate Fenders
Grommet Mount Sealed Lighting
L.E.D. Lighting Package
Sealed Modular Wiring Harness
Spare Tire Mount (Front)
Complete Break-A-Way System w/Charger
Zip Breakaway Cable
Radial Tires
We have over 300 trailers in stock. Stop in and let us show you around. Or call us at 410-335-2218.
Picture posted with ad is model but may not be representative of actual colors/options.
Pricing, specs and availability are subject to change. We are not responsible for typographical errors.
